| Place of Origin: | China |
|---|---|
| Brand Name: | Kingsum ElectronicPCB |
| Certification: | UL, ROHS, REACH, TS16949 |
| Model Number: | PCB-J-001 |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | To be Inquired |
| Delivery Time: | 5-8days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 10000pcs/month |
| PCB Material: | FR4 | Spec: | As Per Customer Gerber Files |
|---|---|---|---|
| Layer: | 2 | Soldmark: | EING |
| Material: | FR4 | Copper: | 2OZ |
| High Light: | custom printed circuit board,pcb printed circuit board | ||
Layer: 1-16
Material: FR4 laminate, RoHS Directive-compliant
PCB thickness: 0.4-6.0mm
Final copper: 0.5-6oz
Min hole: 0.2mm
Min line width/space: 3/3 mil
Min hole copper: 20/25µm
Solder masks: green/blue/red/black/gray/white
Legend: white/black/yellow
Surface: OSP/HAL lead-free/immersion gold/immersion tin/immersion silver/flash gold/hard gold
Outline: rout and score/V-cut
E-test: 100%
Inspection standard: IPC-A-600H/IPC-6012B, class 2/3
Outgoing reports: final inspection, e-test, solderability test, micro section
Certifications: UL, SGS, RoHS Directive-compliant, ISO/TS16949:2009
Manufacturer Capacity:
| Capacity |
Double Sided: 12000 sq.m / month Multilayers: 8000sq.m / month |
| Min Line Width/Gap | 4/4 mil (1mil=0.0254mm) |
| Board Thickness | 0.3~4.0mm |
| Layers | 1~20 layers |
| Material | FR-4, Aluminum, PI |
| Copper Thickness | 0.5~4oz |
| Material Tg | Tg140~Tg170 |
| Max PCB Size | 600*1200mm |
| Min Hole Size | 0.2mm (+/- 0.025) |
| Surface Treatment | HASL, ENIG, OSP |
