| Place of Origin: | Shenzhen China |
|---|---|
| Brand Name: | Kingsum Electronic |
| Certification: | IATF16949-2016 | ISO9001 2015 | UL 337072 | ROHS |
| Model Number: | KZ-H-116 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | 0.1-3usd/pc |
| Packaging Details: | vacuum package |
| Delivery Time: | 7-10days |
| Payment Terms: | T/T, Western Union,paypal |
| Supply Ability: | 20000square meters/month |
| Type: | Industrial Control PCB | Material: | FR4/AL |
|---|---|---|---|
| Components: | Qualified | Min Hole Size: | 3mile(0.075mm) |
| SMT DIP Technology: | Support | Brand Name: | OEM |
| Special Process: | Heavy Copper Thickness | ||
| High Light: |
double sided pcb board,immersion gold pcb |
||
10oz for Internal and External layers#Four layers heavy copper thickness #FR4 Printed Circuit Board.#Multilayer PCB
1.Detailed Specification of PCB
| The number of layers | 4,6,10,12 |
| Material | FR4,AL |
| finish thickness | 1.6-3.0mm |
| The finished copper thickness | 1-10 oz |
| Solder mask color | Blue, Green,Red |
| Silkscreen | White, Black |
| The finished size(PCSandPNL) | customized |
| Surface treatment | HASL,ENIG |
2.Information of Company
Shenzhen Kingsum Electronic Circuit is a manufacturer of PCB and PCBA. Certificates: ISO 9001, UL (E337072), TS16949 (0259279), RoHS We have over 300 employees and 8,000 square meters building area. Our products include Normal Tg FR4, High Tg FR4, PTFE, Rogers, Low Dk/Df, FPC, Rigid-Flex PCB and Aluminum, Copper base PCB, etc. Assembly service including SMT, DIP with six assembly lines. --Providing one stop service for our clients including: -PCB Production (prototype, small & medium production, mass production) -Components Sourcing -PCB Assembly (SMT, SMD, DIP) Our PCB technology capacity includes 1 to 50 layers, minimum dill hole size of 0.1mm, minimum track/line size of 0.075mm, surface treatment of OSP, HAL, HASL, ENIG, Gold Finger and more. We can make our production capacity of 12,000 square meters/month for double sides and 8,000 square meters/month for multilayer.
3.Pictures of PCB
