| Place of Origin: | CHINA |
|---|---|
| Brand Name: | Kingsum ElectronicPCB |
| Certification: | UL,ROHS,REACH,ISO,TS16949 |
| Model Number: | PCB-J-003 |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Vacuum bag |
| Delivery Time: | 5-10days |
| Supply Ability: | 100000pcs/month |
| Material: | FR4 | Surface: | HASL/ENIG |
|---|---|---|---|
| Soldermask: | Red/Green/Black/White | Silkscreen: | White |
| Copper: | 3OZ | Layer: | 2 |
| High Light: | printed circuit board pcb,high frequency pcb | ||
Layer: 1-16
Material: FR4 laminate, RoHS Directive-compliant
PCB thickness: 0.4-6.0mm
Final copper: 0.5-6oz
Min hole: 0.2mm
Min line width/space: 3/3 mil
Min hole copper: 20/25µm
Solder masks: green/blue/red/black/gray/white
Legend: white/black/yellow
Surface: OSP/HAL lead-free/immersion gold/immersion tin/immersion silver/flash gold/hard gold
Outline: rout and score/V-cut
E-test: 100%
Inspection standard: IPC-A-600H/IPC-6012B, class 2/3
Outgoing reports: final inspection, e-test, solderability test, micro section
Certifications: UL, SGS, RoHS Directive-compliant, ISO/TS16949:2009
Manufacturer Capacity:
| Capacity |
Double Sided: 12000 sq.m / month Multilayers: 8000sq.m / month |
| Min Line Width/Gap | 4/4 mil (1mil=0.0254mm) |
| Board Thickness | 0.3~4.0mm |
| Layers | 1~20 layers |
| Material | FR-4, Aluminum, PI |
| Copper Thickness | 0.5~4oz |
| Material Tg | Tg140~Tg170 |
| Max PCB Size | 600*1200mm |
| Min Hole Size | 0.2mm (+/- 0.025) |
| Surface Treatment | HASL, ENIG, OSP |
What Kingsum Electronic Circuit can do for you:
To get a full quotation of the PCB/PCBA, pls provide the information as below:
Company Informaiton:
Kingsum Electronic Circuit is a professional PCB manufacturer from China since 2007, also provide PCB Assembly service for our customers. Now with about 300 employees. Certified with ISO9001,TS16949, UL, RoHS. We are confident to provide you quality products with factory-directed price within the fastest delivery time!
Manufacturer Capacity:
| Capacity |
Double Sided: 12000 sq.m / month Multilayers: 8000sq.m / month |
| Min Line Width/Gap | 4/4 mil (1mil=0.0254mm) |
| Board Thickness | 0.3~4.0mm |
| Layers | 1~20 layers |
| Material | FR-4, Aluminum, PI |
| Copper Thickness | 0.5~4oz |
| Material Tg | Tg140~Tg170 |
| Max PCB Size | 600*1200mm |
| Min Hole Size | 0.2mm (+/- 0.025) |
| Surface Treatment |
HASL, ENIG, OSP |
